LINE DRAWINGS
Gradus Focus pod
dimensions
Find Framery Gradus Focus pods
detailed dimensions below.
GRADUS FOCUS
Main view
GRADUS FOCUS
Front view
* Including ventilation cover, casters and seismic kit.
GRADUS FOCUS
Top view
GRADUS FOCUS
Power cord specifications
- Total power cord length: 23 ft (7 m)
- When installed from the roof: 16 ft (4.9 m)
- When installed from the base: 17 ft (5.3 m)
GRADUS FOCUS
Operating space
Daily pod operation requires some space around the pod. The total required space from back to front (pod depth + doorway) is 80 in / 203 cm. The minimum room height requirement is 92.5 in / 235 cm, which allows for 3.9 / 10 cm in of clearance above the pod.
Framery Gradus Focus pods can be placed next to each other.
Please note:
- For seismic anchoring leave 5 in / 12.7 cm of free space outside of exterior panel walls.
- No additional clearance needed if sprinklered.
GRADUS FOCUS
Installation space
Installation requires 19.7 in / 50 cm of free space around the pod. Room height requirement 92.5 in / 235 cm.
Framery Gradus Focus pods can be placed next to each other.
Please note:
- For seismic anchoring leave 5 in / 12.6 cm of free space outside of exterior panel walls.
- No additional clearance needed if sprinklered.
